Residual Current Operated Circuit-Breaker IS 12640 PART 2 : 2016

BIS CERTIFICATION OF RESIDUAL CURRENT OPERATED CIRCUIT BREAKERS FOR HOUSEHOLD AND SIMILAR USES–PART 2 CIRCUIT BREAKERS WITH INTEGRAL OVERCURRENT PROTECTION(RCBOS) IS 12640 Part 2 : 2016

RCBO is a Residual Current Operated Circuit-Breaker with Integral Overcurrent Protection. A mechanical switching device designed to make, carry and break currents under normal service conditions and to cause the opening of the contacts when the residual current attains a given value under specified conditions.

In addition, it is designed to give protection against overloads and/or short-circuits and can be used independently of any other overcurrent protective device within its rated short-circuit capacity.

Residual current operated circuit breakers for household and similar uses (RCBOs) is used in the following areas –

• Protect people against residual currents
• Protect systems against short-circuit and overload.
•


1. Introduction to Indian Standard IS 12640 (PART 2Residual current operated circuit breakers for household and similar uses (RCBOs)

• IS 12640 (PART 1) cover Residual current operated circuit breakers for house hold and similar uses (RCBOs) without integral overcurrent protection . This standard specifies the manufacturing, chemical and physical requirements and testing of Residual current operated circuit breakers for house hold and similar uses (RCBOs) without integral overcurrent protection.
• IS 12640 (PART 2) specifies the quality parameters or characteristics of the Residual current operated circuit breakers for household and similar uses (RCBOs)as follows
•


Trip-free Mechanism

Electric Strength Test

Tripping Test

Clearance and Creepage distance

Reliability of screws, current-carrying parts and connections

Protection against electric shock and other tests

Reliability of terminals for external conductors

Indelibility of Marking

For more info on the product standardization click here

1. Mandate for ISI Mark Certification of Residual current operated circuit breakers for household and similar uses (RCBOs) to use ISI mark as per IS 12640 (PART 2):

• Under section 14 of Bureau of Indian Standards Act, 1986 (63 of 1986), the Ministry of Commerce and Industry, Department for Promotion of Industry and Internal Trade after consulting the Bureau of Indian Standards has issued the Electrical Wires, Cables, Appliances and Protection Devices and Accessories (Quality control) order.
• As per this Quality Control order, allthe manufacturers of  Residual current operated circuit breakers for household and similar uses (RCBOs) to use ISI mark as per IS 12640 (PART 2) are obligated to obtain ISI Mark Certification.

1. Types of Electrical Household Goods covered under IS 12640 (PART 2)

“Licence is granted to use Standard Mark as per IS 12640(Part 2): 2016/IEC 61009-1 with the following scope:”
Name of the Product	Residual Current Operated Circuit Breakers Without Integral Overcurrent Protection for Household & Similar Uses(RCBO)
Classification	As applicable according to Cl. 4 of IS 12640 (Part 2):2016/ IEC 61009-1:2012

1. Procedure to obtain BIS Certifica tion of Residual current operated circuit breakers for household and similar uses (RCBOs) to use ISI mark as per IS 12640 (PART 2)

For Indian Manufacturers (Standard Timeframe – 30 days) click here

For Foreign Manufacturers (Standard Timeframe – 180 days)click here

1. Requisites to get the BIS license for Residual current operated circuit breakers for household and similar uses (RCBOs)

Conformity of Raw Material as per IS 12640 (PART 2)

In-house testing laboratory for mandatory tests

Competent Quality Control Personnel

Adherence to the BIS guidelines for Residual current operated circuit breakers for household and similar uses (RCBOs) as per Indian standard IS 12640 (PART 2)

There are 3 major categories of document required to get the BIS license:

Administrative Details

Technical Details

Quality Control Personnel Details

Commercial Details

1. Expenses involved in obtaining BIS certificate for Residual current operated circuit breakers for household and similar uses (RCBOs)under the Product Certification (Scheme-I) of BIS :



For Indian Manufacturers
No.	Major Charges		Amount	Remark
1.	BIS Fee	Application Fees	INR 1000	To be paid in BIS A/c directly. 20% rebate on Marking Fee for MSME units.
		Audit Charges	INR 7000
		License Fee	INR 1000
		Marking Fee	INR 112000
2.	Testing Charges	Sample Test Fee	As Applicable	To be paid into BIS approved Lab A/c
3.	ERCS Service Fee	Consultancy & others	As per actual, (Depending upon the product and the region of factory)

For the Foreign Manufacturers
No.	Major Charges	Particulars	Amount	Remark
1.	BIS Fee	Application Fees	USD 30	To be paid into BIS A/c directly in USD (SWIFT). SAARC countries can pay in INR with GST@18%
		Audit Charges (consolidated)	USD 3200 to USD 5900
		License Fee	USD 30
		Marking Fee	USD 1360
2.	Testing Charges	Sample Test Fee	As applicable	To be paid into BIS approved Lab A/c
3.	ERCS Service Fee	Consultancy & other charges	As per actual, (Depending upon the product and the location of mfg.)

• In the certification process, product testing is the most important stage as it determines whether the quality of the product meets Indian standards.
• For the same purpose, investments in testing facilities are required to install test equipment for internal factory test laboratories.
• Apart from charges mentioned above in the table, we may ask you to pay/reimbursement for a Pre-Visit at your Factory Premises to ensure the conformity of your product as per the relevant Indian Standard & BIS guidelines for its BIS certification.

1. Role of ERCS Private Limited in getting your product certified :

• To get BIS certification and produce a standard quality product, the manufacturer must ensure that their product must follow the specified Indian Standard Specifications (ISS) which we directly interpret to you from the BIS officials as per the Indian Standards.
• ECRS Private Limited will be your friend, philosopher and guide in the whole process of getting your product certified by the concerned authorities/ departments.

• Scope of work by ECRS Private Limited:

Ensuring the conformity of your product as per IS 12640 (PART 2):

ERCS Pvt. Ltd. has developed a vast network within the Electrical Household Goods Industry & various BIS departments to assist for ensuring conformity of the product CIRCUIT BREAKERS WITHOUT INTEGRAL OVERCURRENT PROTECTION (RCBOs) according to according to IS 12640 (PART 2).

Effective documentation with the awareness of the BIS guidelines:

In order to facilitate the manufacturing industry in obtaining BIS certifications, guidelines have been developed. Our team has the experience of completing over 150 projects and technically competent acquaintances in various Industries.

We are familiar with the Indian Standard Specifications & BIS guidelines and deliver the most suitable interpretation to the Quality Control Personnel so we can do a reliable and effective documentation of your product in accordance with the BIS guidelines.

A pre-visit can be paid at your factory premises:

In the process of getting BIS certification, the officer from BIS authority visits the factory for inspection. In order to get good results, the BIS inspection should go smoothly without any Non-Conformity. By keeping this goal in mind, our team will organize a pre-visit to your factory premises so that required changes can be adapted so as to remove the elements of fallibility.

Assistance for BIS audits:

We will explain the whole procedure of conducting a BIS inspection and make you aware of the things which need to be prepared and readily available at the time of inspection.

Benefits of getting ISI Mark for Residual current operated circuit breakers for household and similar uses (RCBOs) to sell in Indian Market with our help

• The term “ISI mark" means, that a certain product conforms to the quality standards set up by the government.
• It is compulsory for Residual current operated circuit breakers for household and similar uses–Part 2 Circuit breakers with integral overcurrent protection(RCBOs)to obtain the ISI Mark and the violators are penalized with the material seize and a significant sum as fine.
• Getting certification improves the probability of your product to survive and compete in the market.
• Customers have the tendency of buying ISI certified products as it ensured safety and standard quality. Hence, with the certified products you can win the confidence and trust of the buyer.
• With the word of mouth of such client list, you can establish your credibility in the market.
• Hence with the renowned brand, you can raise the standard and benchmark the market value of the product.
