BIS Certification for Mini Domestic Water Heater for Use with Piped Natural Gas (PNG) IS 17150

IS 17150 is an Indian standard that describes the safety and quality of mini domestic water heating equipment designed to operate with piped natural gas (PNG) and is available for use in India under BIS certification. This is a product generally found in residential settings that require an instant hot water supply. In residential and household applications, mini water heaters are typically used for bathing, cooking, and cleaning.



The market is developing such great momentum that it will entice many traders into the import and export sector. In the following article, we will elaborate on the importance of BIS certification for mini domestic water heaters, the standard specifications and requirements they have to conform to, and the convenience for users and consumers.



Overview of Mini Domestic Water Heater Certification

Mini Domestic Water Heaters by Piped Natural Gas (PNG) are small appliances for household purposes to provide hot water instantly. PNG is considered an energy-efficient energy source for water heating. These heaters are built as you need them for a quick and constant supply of hot water. Therefore, they are good for a small home or kitchen, if you choose to consider these factors. The product has a high-demand market, therefore, BIS certification of the Mini Domestic Water Heater is necessary.



They heat water as it is passing through the unit, which generally allows unlimited hot water from a relatively large storage tank. Although mini storage tank heaters vary in capacities and sizes, these heaters may be smaller and more space-efficient than traditional storage tank heaters. Mini storage tank heaters are usually better to install in smaller homes and apartments.



Key Specification of IS 17150

This standard sets out requirements for instantaneous domestic water heaters having a nominal useful heat output of less than 25 kW (based on the gross calorific value), where the device is connected to Piped Natural Gas (PNG) at a working pressure of 21 mbar (21.41 gf/cm2).

• This standard covers instantaneous domestic water heaters with PNG and a working pressure of 21 mbar, with a nominal heat output of less than 25 kW.
• This standard specifies requirements for the construction of the water heater, which includes materials, design, and components.
• It also covers performance requirements such as heating capacity, gas consumption, and overall efficiency of the water heater. Additionally, it outlines the testing methods used to measure compliance with the safety and performance requirements.
• An inlet water-controlled appliance has the principal constructional and performance qualities specified for the instantaneous domestic water heater. It also determines appropriate test methods to test the different test characteristics.
• The mercurous nitrate test shall be passed by all the copper and copper alloy forged and cast parts (season cracking test). Non-metallic materials normally in contact with the gas shall not undergo a change in weight or volume of more than 15 percent when immersed in pentane for 72 hours at room temperature.
• The gas inlet connection shall provide for a rigid connection. All water connections shall consist of copper or brass tubes with an internal diameter not less than 6 mm and with a wall thickness of not less than 0.5 mm.
• The gas and water connections shall be located at the base of the appliance. It shall be possible to connect the appliance to a supply located in a plane parallel or perpendicular to the wall upon which the appliance is fixed.
• The flame failure device shall control the admission of gas to the main burner and, in some cases, to any ignition pilot.
• An ignition device shall be fitted to the appliance. If it is provided in the form of a pilot, then it shall be possible to light it with ease, either using a matchstick or by a special ignition device.



BIS Certification Scope of Mini Domestic Water Heater under IS 17150

This standard applies to instantaneous-type domestic water heaters with a nominal useful heat output of less than 25 kW (based on gross calorific value), for use with piped natural gases (PNG) at a working pressure of 21 mbar (21.41 gf/cm?). It uses water inlet control and sets out the main constructional and performance characteristics for an instantaneous domestic water heater. It also sets out suitable test methods for a selection of test characteristics. It does not cover appliances for boiling water.

This standard has been divided into three sections for convenience:

• Section 1 — Construction
• Section 2 — Performance requirements
• Section 3 — General



Process for Getting BIS Certification for Mini Domestic Water Heater IS 17150

The steps for obtaining a BIS certificate for any mini domestic water heater according to IS 17150 include determining the relevant Indian Standard, applying to BIS, factory inspection, testing of the product, and certification decision:

• Determine the Relevant Indian Standard: The manufacturer must be sure that the correct standard is IS 17150:2019 for their mini domestic water heaters.
• Application Submission: The manufacturer must complete the BIS application form, along with all the required documents, and submit them.
• Factory Inspection: BIS inspectors will visit the factory for an audit to assess their manufacturing methods and the quality control measures in place.
• Sample Testing: The manufacturers will not be aware that the BIS inspectors will require samples of the products. The samples will be sent to a BIS-approved laboratory to see if they meet the standard.
• Certification Decision: BIS will decide whether or not to award the certification, based on the inspection of the factory and the results of the laboratory samples.
• Grant of License: If satisfactory, BIS will grant a license to the manufacturer to allow them to use the ISI Mark.



What are the timelines for Mini Domestic Water Heater BIS Certification?

There are different BIS certification periods for the different types of producers. The main classifications are: BIS Certifications for Indian Manufacturers (which is typically issued within 30 days) and BIS Certifications for Foreign Manufacturers (which is typically issued within 180 days).



Essential Documents Required Under BIS Certification for Mini Domestic Water Heater

Let’s go through the required documents for BIS product certification:

1. Application Form: A formal application formally stating the details of the manufacturer and the product under consideration for certification; Manufacturing Process

• Details: A description of the manufacturing processes with proposed flow chart, layou,t and equipment;
• Quality Control Plan: Documentation of the quality control activities during the manufacturing process.

2. Test Reports: Test reports indicating that the water heater complies with the requirements of the concerned Indian Standard are necessary.

3. Factory Layout and Equipment Details: This refers to the factory layout and connections of the equipment utilized.

4. Proof of Business Registration: To lawfully validate the status of the manufacturer.

5. Product specifications and technical information: This comprises the technical information about the water heater's design, functionality, and performance.



BIS Certification Cost for IS 17150

Go through the table to know the cost of BIS Certification for IS 17150:

How ERCS Helps in Obtaining BIS Certification?

Producers who want to manufacture a product under IS 17150 with flawless conformity to Indian Standard Specifications can avail end-to-end assistance in product certification. All you need is a BIS certificate agent.



ERCS, as the best BIS consultants in India, ensures document preparation according to BIS specifications. Due to their vast experience with over 100 projects and knowledge of Indian standards, manufacturers can attain the necessary quality control standards. Pre-visit factory inspections are conducted by ERCS to detect and rectify any possible non-conformities.



This forward-thinking strategy accelerates the official BIS inspection process and guarantees adherence. ERCS will help producers by delineating through the BIS audit what paperwork is required and what type of inspection needs to be done to enhance the likelihood of passing.
